PS-347-NR-12-100mA

PS-347-NR-12-100mA

Power Supply (12VDC)

Provides 12VDC to occupancy sensors, load controllers and other similar devices. For applications where line voltage switching is not required.

20A relay to control multiple fixtures in a lighting zone.

Incorporates universal input (120~347VAC) line voltage transformer.

Download Specsheet


Contact Us

Accessory

Product details

Dimensions
3.02" x 1.87" x 1.06"
(76mm x 47mm x 27mm)
Electrical
Input Voltage : 120V~347VAC
Current Consumption: 50/60Hz

Output: 12 VDC, Max 0~100 mA
Mechanical
Indoor Use
Max Case Temperature: 90°C
Operating Temperature: -40°C to 70°C for 120~347V Electronic Ballast, CFL and LED
-40°C to 50°C for 277V Std. Ballasts
-40°C to 50°C for 120V Tungsten
-40°C to 40°C for 230V Tungsten

Relative Humidity:10-95% non-condensing
Certification
cULus, CE
